By Mike from Russellville, KY on February 28, 2013
What does "square end" mean?
By Tyler M. - NFI Certified Specialist on February 28, 2013
Answer:"Square end" refers to the shape of the hood itself, which you can see in the picture/diagram above
By John on November 9, 2012
We had a builder build us an outdoor fireplace with a 42” wide opening. The opening height is about 30” and there is a wide slit-type damper across the width of the fireplace. The damper is at the same height as the opening, and of course we get smoke coming out of the front of the fireplace.
The ceiling of the firebox or fireplace is flat; it would seem I need a hood or some kind of screen that comes down from the top of the opening about 6-8” to trap the smoke so that it goes up the chimney and not out the front opening. Do you have a hood or any other suggestions? I assume the builder should have built it a bit differently.
on November 9, 2012
Answer:You are correct about the build of the fireplace. In order for a large fireplace like this to draft properly, the builder should have built a smoke chamber into the roof of the fireplace. This would be a cavity that extends upwards by about 12-18 inches, then narrowing down to a small damper opening. This creates a funneling effect and draws the smoke upwards.
Most likely, it would be best to install a metal smoke shelf across the top of the opening, in order to create a bit of an artificial smoke chamber. In order to test if this will work, I would recommend purchasing a piece of scrap plywood or sheet metal, then building a fire in the fireplace, and then hold the metal or wood across the top of the opening, covering about four inches of top.
If this helps, purchasing and installing the guard would be the best route. I am also curious as to if the chimney is sized properly. Given the size of the opening, you would need a 12" round or 11" square flue tile. Please advise as to what size has been used.
By Bob on November 9, 2012
Do you have actual pictures I may view?
I have three mounting screw holes along the top of the hood and one on each side for the flange sides. I want to make sure I order one that is in a direct slip-in on the one I am replacing. Mine is 36 inches wide. I would like to get flat black or powder black one.
on November 9, 2012
Answer:Most of our hoods are a universal design that will most likely not be a direct fit replacement. However, we do carry some models of hoods that are a factory accessory for certain fireplaces. Do you happen to have any manufacturer and model information for the fireplace?
Please advise at your convenience.
By Louis on November 9, 2012
I need to minimize my fireplace opening due to my flue not being an adequate size. (Smoking problems beyond cleaning of the flue) Would a fireplace hood be sufficient to resolve this problem? Not sure if it should be a hood or a flat plate in the opening to reduce the free net area. Please advise.
on November 9, 2012
Typically, a hood would not be enough to alleviate this issue. You would be better off with a smoke guard, which is designed to alleviate the oversize condition you have now. Please view our sizes at the links below:
Smoke Guard 1
Smoke Guard 2
The ideal opening-to-flue ratio is 10 to 1: ten square inches of opening to one square inch of flue.
By Tony from Apex, NC on December 12, 2012
I have a BIS Panorama fireplace (wood-burning) that works good. However, my wood mantel gets much too hot. If I order the 6" hood and the mantel still gets too hot, can I return the hood for a refund? Also does the hood come in a black color?
By Collin C. - NFI Master Hearth Professional on December 12, 2012
Answer:My apologizes, but I do not see any past emails regarding this fireplace. We do offer universal style hoods with a 6-inch projection that can be surface mounted above the fireplace, but they are made to order and cannot be returned. We also offer the hood in a matte black color.
By David from Longmeadow, MA on December 5, 2013
The standard 42 x 4 hood that attached to a set of glass doors indicates that they are custom made by the manufacturer and can not be cancelled or returned once the order is placed unless the item is defective or damaged in transit. How can this be if they are an in stock and pre-made/available to ship?
This does not make sense and I would think that custom made means that they can cut it to specifications. I would like to purchase a matte black hood but I won't know if it matches my current door which appears to be matte black, but I am not certain. Would I be able to return this if the color did not match?
By Collin C. - NFI Master Hearth Professional on December 6, 2013
Answer:Each of the Elite hoods is custom made by the manufacturer in Lenexa, KS. They have a full time manufacturing facility that can produce a hood the same day an order comes in and they usually ship the hood the next day. If you have an exact width that you would like the hood to be, we can certainly have that done. Because the hoods are indeed custom made, returns are not accepted. However, if you are concerned about the color of the hood matching, I can certainly check with the manufacturer to see if a color sample could be mailed to you. What is the width that the hood would need to be for your application?
By Mark from Hampton, Virginia on November 3, 2013
I'm curious which fireplace hood I need (if any). I recently purchased a house that has a "Superior BC-36" type fireplace. It looks like there are various types/sizes of these hoods. I do not have a mantel, but I do have a painting above the fireplace. Can you give me any advice or help?
By Collin C. - NFI Master Hearth Professional on November 4, 2013
A hood is not included as a standard feature on the BC36 fireplace, however a universal model can be added. Use of a hood will depend primarily on the type of fuel you burn in the unit and how it is vented. For wood burning or vented gas applications, the unit will not release enough heat to warrant the installation of a hood. However, a universal surface mount hood would be an excellent idea if a vent free gas log set or glass burner is used. These types of appliances release a great deal of heat that could damage anything above the fireplace.
A universal hood that could work is the Elite Square End Fireplace Hood with Lintel Mount - 36 Inch x 4 Inch
. The hood can be specified in matte black and can be attached to the inside top of the fireplace opening. This will deflect heat further into the room.
By Donna from Carmel, IN on April 6, 2013
I have a ventless gas fire place and my mantel gets so hot that the paint of the surround under the mantel has bubbled from the heat. What can I do to fix this? Would a fireplace hood help?
By Collin C. - NFI Master Hearth Professional on April 8, 2013
Answer:A hood can indeed serve as a good way to protect your mantel from damage. The projection of the hood will depend on how much space is between the fireplace opening and the mantel. Projection of the mantel will also be key.
By Kim Beeland from Aiken, SC on November 1, 2012
Do you have a fireplace hood that will attach to marble? Our gas fireplace has marble surrounding it and we don't want to drill into it.
By Tyler M. - Fireplace Specialist on November 1, 2012
Answer:Our surface mount hoods would require that you drill into the marble. We also have hoods that attach to the fireplace lintel and hoods that attach to a glass enclosure (doors.)
By Catherine from Tennessee on January 9, 2014
I am trying to figure out which kind of hood I need for my fireplace. How wide of an area do you need to attach a surface mount hood? Is a 1 inch strip of wood above the fireplace enough? How about a lintel mount? I would only have about a half inch to attach a lintel mount.
By Collin C. - NFI Master Hearth Professional on January 9, 2014
Answer:The width of the attachment area for a surface mount hood is approximately 3/4 of an inch, so it could work for your application. The hood is best to overlap the entire fireplace opening for best coverage. Please keep in mind that the hood will have a height of 3 1/2 inches.
By Kristi from Wichita, KS on December 17, 2012
I am getting ready to convert gas logs to wood-burning ones. I have a flat screen TV mounted above the fireplace. Will a hood divert the heat and keep it from reaching my TV and damaging it?
By Collin C. - NFI Master Hearth Professional on December 18, 2012
Answer:A hood can deflect heat around the television, as long as the television does not project more than 2 inches further than the hood itself. For example, a 6-inch hood could protect a TV that projects up to 8-inches from the wall.
By Bruce from Danville, CA on February 4, 2014
What is a lintel mount? Can I use it with a tile face front fireplace?
By Collin C. - NFI Master Hearth Professional on February 4, 2014
Answer:Lintel mount fireplaces have a metal extension that allows you to secure the hood to the metal lintel bar that runs across the top of the opening in a masonry fireplace. The type of facing on the fireplace will not matter in this case, as long as you have the flat bar to attach the hood to.
By Gary Evans from Alabama on November 14, 2012
How does a lintel mount hood attach? We have a beautiful brick front fireplace and do not want to drill holes in it.
By Magan B. on November 15, 2012
Answer:A lintel mount hood would be installed on an existing lintel on a fireplace. If you have a lintel, it will be located beneath the bricks at the top of the firebox. A lintel mount hood will attach to the lintel with screws.
By Alan from Morristown, NJ on December 10, 2012
What do you recommend for an older fireplace where we are converting to a gas burner setup? We have the recommended setup, but found their hood was an expandable one: it looks terrible and is flimsy. We need a non-brass one piece. We usually found the ones mounted on the outside have flanges and screws that will be seen, so we expect the only decent looking ones are internally mounted (lintel mounts).
We also expect to use a screen for the rest of the setup, but the hood is needed as we only have 21" to the mantel. Our brick opening is 35", so if we can mount a larger one like 36", 37", etc. then that is fine if it can protrude beyond the edges. It depends on the mount.
By Collin C. - NFI Master Hearth Professional on December 10, 2012
Lintel mount hoods are indeed the least intrusive of all mount types, although they do need to be an exact width to fit the opening properly. However, it is not an issue to request the fabricator to cut the hood down to the proper width.
We can also request the hood to be made in matte black, as this is often the most popular choice. I am not sure on the projection needed, but the Elite Square End Fireplace Hood with Lintel Mount - 36 Inch x 4 Inch
may suit your needs. We also offer this in a 6-inch projection, which can also be cut down to the needed size.
By David from Longmeadow, MA on December 3, 2013
In one of the questions answered previously you explained that it is not an issue to request the fabricator to cut the hood down to the proper width. Is this something that can be done by the manufacturer before shipping?
I have a glass door on the exterior of the firebox that is 37.5" wide. I would like to purchase a hood that attaches to the back of the door and wraps around to the front. The closest dimension is 42 inches wide and I would rather stay away from the adjustable hoods.
By Collin C. - NFI Master Hearth Professional on December 4, 2013
Answer:The fabricator can indeed produce the hood to an exact dimension. We would simply need to specify this when the order is placed. Because there is not an effective way to do this through our online ordering system, it is best for us to speak to you over the phone to place an order manually. This will ensure that the order is properly noted for the hood to be cut down.
By quynh from Texas on November 3, 2012
I did not know there were so many different types of fireplace hoods. The one I have just pops in and out of place. I was wondering if you have one like that? It is 36 inches.
By Collin C. - NFI Master Hearth Professional on November 5, 2012
Answer:The hood you have sounds like a model that is specific to the fireplace itself. Most of the hoods we carry are universal models that must be screwed into place.
In order to find the correct part number for the type of hood you have, you will need to locate the model number and manufacturer name of the fireplace. This information can usually be located on a build tag in the bottom of the unit or on the firebox wall, just inside the opening.
By Elaine Sanford from Memphis, TN on February 6, 2013
How do I properly measure for the fireplace hood? Should I measure just the face width of the fireplace itself? Or should I include the space on either side of the fireplace, which includes the width of my glass fireplace cover?
By Collin C. - NFI Master Hearth Professional on February 6, 2013
Answer:If your glass fireplace cover is an operable door assembly, you will need to measure from the outside to the outside of the assembly. If the cover is a fixed pane of glass, you will want to measure to the metal on either side of the glass panel.
