    Gas Log Valves and Safety Pilots

    Gas log valves and safety pilots are important additions to your gas log set. Gas log valves allow you to turn the gas flow on and off as needed, and safety pilot kits can keep a pilot burning so you don't have to relight every time you turn on your gas logs. Set yourself up for added safety and ease of use by choosing the right gas log valve or safety pilot kit for your gas log set.
    Select
    Ask & Answer
    Ask a Specialist
    23 Questions & 22 Answers
    Rolf Amundson
    from Wyoming asked:
    January 18, 2017
    I have a fine diffusion screen over one of the gas outlet tubes. It has some minor damage, and I would like to replace it. Do you have some of this screen for sale? Screen needed is approximately 2" X 16".
    1 Answers
    No, we do not.
    Owen
    on January 18, 2017

    Susan
    from Dallas, Texas asked:
    December 23, 2016
    I need a new pilot kit replacement for a Peterson unit: SPK20 or SPK21.
    1 Answers
    I will be happy to link a replacement. Will this be for natural gas or propane?
    Brennan W.
    on December 26, 2016

    Albert D. Thompson
    from New Braunfels, TX asked:
    November 10, 2016
    My old valve is at the left of the tray instead of the right, as most are shown. Can a cap be put on the tray [one the left] and use the SPK valve, shown to hook up to the right of the tray? Are all trays alike, and will fit this new valve?

    Wilbur
    from MO asked:
    October 30, 2016
    I need a replacement pilot assembly for a gas log fireplace, FMI model # GL2000, serial #WHI1328. It is a natural gas unit. I believe the mfg. part number is 22873.
    1 Answers
    For replacement parts, please fill out this form.
    Will M.
    on October 31, 2016

    Ed
    from Woodbury, NJ asked:
    October 20, 2016
    I have an Empire VFSE gas log set, serial #12026311185. I need to convert it to natural gas. What will I need?
    1 Answers
    Unfortunately, as your log set is unvented, it is unable to be fuel converted.
    Brennan W.
    on October 20, 2016

    Bob
    from Pittsburgh, PA asked:
    March 7, 2016
    Will any of these valves work on a ventless log setup?
    1 Answers
    Unfortunately, none of these are approved for vent free log sets.
    Brennan W.
    on March 7, 2016

    Edwin
    from Tucson, AZ asked:
    January 22, 2016
    I have an FMI Alpine 042NRB outdoor fireplace that is about 3 years old and it has been working fine until now. The pilot is on but the burner will not ignite. I have tried to turn it on both manually and with the remote but still nothing. You can hear the remote beep when pressed but it will not ignite the burner. What would you suggest to do to troubleshoot this?
    1 Answers
    This sounds like an issue with the thermocouple not being able to sense the pilot flame. To start, we would suggest taking a piece of emory cloth or 1000 grit sandpaper and cleaning the thermocouple. This should allow the proper millivoltage to get to the valve and allow for the burner to open.
    Brennan W.
    on January 22, 2016

    Peter
    from Clarendon Hills, IL asked:
    December 27, 2015
    I have Monessen Serenade linear fireplace and want to know if there is a way to attach a gas valve to control (turn down) the heat. It seems like there should be a way to control the gas flow beyond the three levels and I want to know if anyone knows a way to do that. Can this be done?
    1 Answers
    Unfortunately, the integral 3 step regulator is the only way to turn output down on this model. The gas valve used in this unit requires constant input pressure to work properly, so turning pressure down on the input side is not a possibility and the output regulator currently installed turns pressure down to the minimum that the manufacturer allows without causing too much fuel deration, which could damage the burner.
    eFireplaceStore
    on December 28, 2015

    Mark
    from Madison, WI asked:
    October 29, 2015
    I am on your web site looking at part AV-18 - which is a manual gas value. What size of pipe does that fit? I am looking for one for 3/8" fittings.
    1 Answers
    The AV-18 is designed to connect to a 1/2" gas line. To connect to a 3/8" line, an adapter would be needed. However, our Ambient MANVK Manual Valve Kit features 3/8" connections.
    Chris C.
    on October 29, 2015

    Brad
    from Denver, CO asked:
    May 11, 2015
    I have a older 1980's gas valve made my Robert H. Patterson. Model #SPK-20. I am looking for a replacement valve that preferably would mount same without replacing my gas feeding line. What valve would I need?
    1 Answers
    The proper replacement kit for your SPK-20 valve would be the Real Fyre SPK-26 Safety Pilot Kit for Natural Gas Logs. Please bear in mind that this is for natural gas. If you are using propane, please let us know and we will suggest the proper kit.
    Brennan W.
    on May 12, 2015

    Cynthia
    from Salt Lake City, UT asked:
    December 15, 2014
    I have an older burner plate, no clue as to who the manufacturer is, and the piping that attaches to it is 1/2" which seems pretty standard for gas lines to fireplaces. Will this pilot valve work for my piping? Is there a generic or universal safety pilot that fits most natural gas burners?
    1 Answers
    We do indeed carry a safety pilot kit that works with almost all vented burner assemblies. The product is the Copreci 172UPK Universal Safety Pilot Kit with Side Inlet Valve. The fittings included should accommodate most installations without an issue.
    eFireplaceStore
    on December 16, 2014

    Jeff
    from Greenville, NC asked:
    September 17, 2014
    I need two gas log fires. The houses have chimneys. I have one of the steel frames on which the logs were placed, but the valve is missing and the logs. Can I buy a new valve and logs and a complete fire? The frame is 20 inches and the fires were inexpensive.
    1 Answers
    From the sound of it, you will likely need to replace the system in its entirety. Low cost sets do not yield themselves to being mixed with replacement parts from other brands. They are most often sold as a complete kit that only works well with the original parts.
    eFireplaceStore
    on September 17, 2014

    Bill
    from Springfield, VA asked:
    January 26, 2014
    I have a Peterson Real-Fyre G10-24/30-15M(P) Remote-Ready natural gas burner system and the piezo ignitor will not click/spark when operated. The batteries for the remote system are good. The wire connections are also are good. Any other troubleshooting ideas? If not, can I purchase a replacement valve assembly?
    1 Answers
    When the main control knob is turned past the ignitor position to create the spark, can you feel the usual amount of resistance that is present or has the feel of the control changed? Another thing to check is the position of the ignitor electrode in relation to the pilot hood. You can bend the electrode slightly closer to the hood and this may fix the issue. If not, a replacement valve body will be needed.
    Collin C. - NFI Master Hearth Professional
    on January 27, 2014

    John
    from Beckley, West Virginia asked:
    November 25, 2013
    I have a Buck stove. It is ventless and natural gas. The pilot light burns but when I turn it on for heat, no flames come out. What could be wrong?
    1 Answers
    There are a number of issues that could be causing this problem. The first is regarding the pilot assembly itself. If the pilot is dirty and has not been serviced recently, the voltage output can be too low and the main burner will not light. With the pilot shut down, I recommend blowing out the pilot assembly with compressed air, then lightly sanding the thermocouple probe to remove any corrosion byproducts that have built up. If this still does not solve the issue, the pilot assembly has likely gotten weak enough that it will need to be replaced.
    Collin C. - NFI Master Hearth Professional
    on November 26, 2013

    Debbie
    from Atlanta, Ga asked:
    May 7, 2013
    Do you have a replacement for a Mertik Maxitrol control valve system, part number GV34-B4AONTH5OL.
    1 Answers
    After checking with the manufacturer, I have learned that this valve is still in production. However, we do not have a distributor that carries it or another Maxitrol valve that is a direct replacement. My recommendation would be to check with a local gas company to see if they can special order Maxitrol products. Plumbing and HVAC distributors can also order these valves. I apologize that I cannot procure this item.
    Collin C. - NFI Master Hearth Professional
    on May 9, 2013

    Ray
    from Reading, PA asked:
    March 25, 2013
    I have a Peterson G10-24/30-15M(P) Vent Free Log set. I want to purchase the entire valve assembly. Can I get a replacement valve assembly for a propane gas log set?
    1 Answers
    Unfortunately replacement parts are not available for vent free log sets. This is a safety precaution.
    Dawn H.
    on March 25, 2013

    Mary Repischak
    from Pittsburgh, PA asked:
    December 9, 2012
    Just noticed that the pilot light flame is double its normal size. Do we need to be concerned, and how do we turn it down to the normal size?
    1 Answers
    If the pilot frame is going far beyond the thermocouple probe, the pilot may be adjusted too high. The gas valve assembly will have a slotted adjustment screw, which can be used to lessen the pilot output. However, this must be done in small increments, as the flame still needs to engulf the thermocouple probe.
    Tyler M. - Fireplace Specialist
    on December 10, 2012

    Sam
    from Erwin, TN asked:
    December 5, 2012
    What are some of the new safety features in the past few years, that are on new gas logs, and that have been mandated by the government?
    1 Answers
    The only major item that has been added to these sets is the inclusion of an oxygen depletion sensor. This system will cause the unit to shut down should oxygen levels in the room drop below safe levels.
    Collin C. - NFI Master Hearth Professional
    on December 5, 2012

    Martin Cappelli
    from Johnston, RI asked:
    December 1, 2012
    I have the Fryer ventless gas log set. It was working fine, then it just shut off - pilot out. We were sitting in front of it when it shut right down. I have natural gas in the house. We have never had a problem. The pilot was always on. What could be the problem?
    1 Answers
    The most common ailment with ventless log sets is dust and lint accumulating in the pilot assembly. It is recommended to use a can of compressed air and a damp rag to remove any buildup that has occurred in the pilot. Depending on the valve you have, you may also need to check/clean the air shutter, as this is another common spot for lint to build up. If this does not solve the issue, you may have another problem with the pilot or valve.
    Collin C. - NFI Master Hearth Professional
    on December 3, 2012

    Brian Sandlin
    from Texas asked:
    November 18, 2012
    Is there a simple explanation of the differences between pilot lights?
    1 Answers
    For standing pilot lights, the basic difference is how the system will be controlled. The first option is manual control. For this option, the system is started by turning a knob on the pilot. The second option is remote control. In this case, the system may be started with a remote or wall switch. For electronic pilots, there will be no standing pilot light.
    Magan B.
    on November 19, 2012

    Darryl
    November 9, 2012
    I have a remote control for a gas log set. It has a standard pilot light. The model is Mertik Maxitrol model G30-ZRHD. It stopped working. I replaced the batteries in both the transmitter and the receiver, but it still does not work. Any suggestions?
    1 Answers
    The first thing I would check is the output voltage from the receiver. If you have a voltage tester or a 12v test light, you will be able to check the voltage from the contacts on the back of the receiver. When a remote function is pressed, the receiver should send between 9-12 volts to the valve. If you do not get a reading when this is done, please verify that there is not a "learn" function on the receiver that needs to be reactivated. If there is a learn function on the unit, there will be a small button on the face of the receiver that will be labeled as such. When pushing this button, the receiver should make an audible beep. You can then push any button on the remote until you hear another beep from the receiver. The learn function is then complete and you should be able to operate the set. Please let me know if I can assist you in any other way.
    on November 9, 2012

    Cindy
    November 9, 2012
    We have Peterson gas logs model G46-24-11M. The box where 4 batteries are has melted, so the remote will not work. Do you sell remote part VR-1A?
    1 Answers
    We do sell the VR-1A remote, but we only offer it complete with receiver and hand-held transmitter. You can see the item here: VR-1A remote. Please let us know if you have any additional questions.
    on November 9, 2012

    Ron
    from Hawaii asked:
    October 25, 2012
    What parts do I need to convert a natural gas ceramic log set to liquid propane?
    1 Answers
    This depends on the manufacturer and model of your log set.
    Tyler M. - Fireplace Specialist
    on October 25, 2012
